CCNA 4 Final Exam 2011 (Updated)

1.

CCNA 4 Final thumb CCNA 4 Final Exam 2011 (Updated)

Refer to the exhibit. Which statement is true about the Frame Relay connection?

The Frame Relay connection is in the process of negotiation.

A congestion control mechanism is enabled on the Frame Relay connection.

The “ACTIVE” status of the Frame Relay connection indicates that the network is experiencing congestion.

Only control FECN and BECN bits are sent over the Frame Relay connection. No data traffic traverses the link.



2. What will be the result of adding the command ip dhcp excluded-address 192.168.24.1 192.168.24.5 to the configuration of a local router that has been configured as a DHCP server?

Traffic that is destined for 192.168.24.1 and 192.168.24.5 will be dropped by the router.

Traffic will not be routed from clients with addresses between 192.168.24.1 and 192.168.24.5.

The DHCP server will not issue the addresses ranging from 192.168.24.1 to 192.168.24.5.

The router will ignore all traffic that comes from the DHCP servers with addresses 192.168.24.1 and 192.168.24.5.



3. What are the symptoms when the s0/0/0 interface on a router is attached to an operational CSU/DSU that is generating a clock signal, but the far end router on the point-to-point link has not been activated?

show controllers indicates cable type DCE V.35. show interfaces s0/0/0 indicates serial down, line protocol down.

show controllers indicates cable type DCE V.35. show interfaces s0/0/0 indicates serial up, line protocol down.

show controllers indicates cable type DTE V.35. show interfaces s0/0/0 indicates serial up, line protocol down.

show controllers indicates cable type DTE V.35. show interfaces s0/0/0 indicates serial down, line protocol down.

(more…)

CCNA Exploration 4 Final Exam 2011

1.

CCNA 4 thumb CCNA Exploration 4 Final Exam 2011

Refer to the exhibit. Communication between two peers has failed. Based on the output that is shown, what is the most likely cause?

interface reset

unplugged cable

improper LMI type

PPP negotiation failure



2.

CCNA 4 Final thumb CCNA Exploration 4 Final Exam 2011

Refer to the exhibit. A network administrator is configuring Frame Relay on router HQ. It is desired that each Frame Relay PVC between the routers be in a separate subnet. Which two commands on HQ will accomplish this task for the connection to R1? (Choose two.)

HQ(config)# interface S0/0/0

HQ(config)# interface S0/0/0.1 multipoint

HQ(config)# interface S0/0/0.1 point-to-point

HQ(config-subif)# frame-relay interface dlci 103

HQ(config-subif)# frame-relay interface dlci 301

HQ(config-if)# frame-relay map ip 172.16.1.1 255.255.255.0 301 broadcast



3. A network administrator is tasked with maintaining two remote locations in the same city. Both locations use the same service provider and have the same service plan for DSL service. When comparing download rates, it is noticed that the location on the East side of town has a faster download rate than the location on the West side of town. How can this be explained?

The West side has a high volume of POTS traffic.

The West side of town is downloading larger packets.

The service provider is closer to the location on the East side.

More clients share a connection to the DSLAM on the West side.

(more…)

CCNA Exploration 4 Final Exam Answers

1. CCNAExploration4FinalExamAnswers thumb CCNA Exploration 4 Final Exam Answers
Refer to the exhibit. What is the meaning of the term dynamic in the output of the command?

The bandwidth capability of the interface increases and decreases automatically based on BECNs.

The Serial0/0/1 interface acquired 172.16.3.1 from a DHCP server.

The mapping between DLCI 100 and 172.16.3.1 was learned through Inverse ARP.

DLCI 100 will automatically adapt to changes in the Frame Relay cloud.



2. CCNA4Final thumb CCNA Exploration 4 Final Exam Answers
Refer to the exhibit. What can be concluded from the exhibited output of the debug ip nat command?

The 10.1.1.225 host is exchanging packets with the 192.168.0.10 host.

The native 10.1.200.254 address is being translated to 192.168.0.10.

The 192.168.0.0/24 network is the inside network.

Port address translation is in effect.



3. Which data link layer encapsulation protocol is used by default for serial connections between two Cisco routers?

ATM

Frame Relay

HDLC

PPP

SDLC

(more…)

CCNA Exploration 4 Chapter 8 Exam Answers

1. Which two statements are true concerning logical networking models? (Choose two.)

TCP/IP splits the lowest layer of the OSI model into two separate layers.

The top layer of the TCP/IP model combines the functions of the top three OSI layers.

Troubleshooting with the TCP/IP model requires different techniques than with the OSI model.

The network access layer is responsible for exchanging packets between devices on a TCP/IP network.

The Internet layer provides communication between applications, such as FTP, HTTP, and SMTP on separate hosts.

The TCP/IP network access layer corresponds to the OSI physical and data link layers.



2. Which two pieces of information are typically found on a logical network diagram? (Choose two.)

cable types

connector types

interface identifiers

DLCI for virtual circuits

operating system versions



3. When gathering symptoms for troubleshooting a network problem, which step could result in getting an external administrator involved in the process?

narrowing the scope

gathering symptoms from suspect devices

analyzing existing symptoms

determining ownership

(more…)

CCNA Exploration 4 Chapter 7 Exam Answers

1. What are two benefits of NAT? (Choose two.)

It saves public IP addresses.

It adds a degree of privacy and security to a network.

It increases routing performance.

It makes troubleshooting routing issues easier.

It makes tunneling with IPsec less complicated.



2. How many bits of an IPv6 address are used to identify the interface ID?

32

48

64

128



3.

CCNAExploration4Chapter7ExamAnswers thumb CCNA Exploration 4 Chapter 7 Exam Answers

Refer to the exhibit. IPv6 address 2006:1::1/64 eui-64 has been configured on the router FastEthernet0/0 interface. Which statement accurately describes the EUI-64 identifier configuration?

It will randomly generate a 64 bit interface ID.

It will assign an address from the pool of IPv6 private addresses to the interface.

It will assign only the registry prefix of the IPv6 Global Unicast address to the interface.

The configuration will derive the interface portion of the IPv6 address from the MAC address of the interface.

(more…)
